Harvia Vega

Description

Harvia Vega is a modern and easy-to-use heater by the world’s largest sauna heater manufacturer. The stainless steel outer shell of Vega is durable and creates a modern look for your sauna. The operating switches are placed ergonomically in the upper part, and thanks to the symmetric shape of the heater, the switches can be placed on either side. The heater can be mounted low on the sauna wall, ensuring that the lower benches also get plenty of steam.

The Vega models BC45, BC60, BC80 are equipped with a built-in control unit. The models BC45E, BC60E, BC80E and BC90E are controlled by a separate control unit (i.e. Harvia C90, Griffin, Xenio)

For more information please read manual. Harvia Vega manual.

Does not include sauna stones.



Model	BC45
Color	Steel
Output kW	4,5
Weight kg	11
Dimensions depth cm	31
Dimensions width cm	48
Dimensions height cm	54
Sauna room min. m3	3
Sauna room max. m3	6
Sauna min. height	190
Stone capacity max. kg	20 (Ø 5–10 cm)
Supply voltage 3-phase	400 V 3N / 230 V 1N
Connecting cable mm2	5 x 1,5 / 3 x 2.5
Fuse A	3 x 10 / 1 x 20



Model	BC60
Color	Steel
Output kW	6,0
Weight kg	11
Dimensions depth cm	31
Dimensions width cm	48
Dimensions height cm	54
Sauna room min. m3	5
Sauna room max. m3	8
Sauna min. height	190
Stone capacity max. kg	20 (Ø 5–10 cm)
Supply voltage 3-phase	400 V 3N / 230 V 1N
Connecting cable mm2	5 x 1,5 / 3 x 6
Fuse A	3 x 10 / 1 x 35



Model	BC80
Color	Steel
Output kW	8,0
Weight kg	11
Dimensions depth cm	31
Dimensions width cm	48
Dimensions height cm	54
Sauna room min. m3	7
Sauna room max. m3	12
Sauna min. height	190
Stone capacity max. kg	20 (Ø 5–10 cm)
Supply voltage 3-phase	400 V 3N / 230 V 1N
Connecting cable mm2	5 x 2,5 / 3 x 6
Fuse A	3 x 16 / 1 x 35
